JL Audio MX600/3 MX Series Class D 3-Channel Car Amplifier - 100W x 2 + 400W x 1 - High Power Audio System for Cars, Trucks & SUVs - Perfect for Upgrading Your Vehicle's Sound System
JL Audio MX600/3 MX Series Class D 3-Channel Car Amplifier - 100W x 2 + 400W x 1 - High Power Audio System for Cars, Trucks & SUVs - Perfect for Upgrading Your Vehicle's Sound SystemJL Audio MX600/3 MX Series Class D 3-Channel Car Amplifier - 100W x 2 + 400W x 1 - High Power Audio System for Cars, Trucks & SUVs - Perfect for Upgrading Your Vehicle's Sound SystemJL Audio MX600/3 MX Series Class D 3-Channel Car Amplifier - 100W x 2 + 400W x 1 - High Power Audio System for Cars, Trucks & SUVs - Perfect for Upgrading Your Vehicle's Sound SystemJL Audio MX600/3 MX Series Class D 3-Channel Car Amplifier - 100W x 2 + 400W x 1 - High Power Audio System for Cars, Trucks & SUVs - Perfect for Upgrading Your Vehicle's Sound System

JL Audio MX600/3 MX Series Class D 3-Channel Car Amplifier - 100W x 2 + 400W x 1 - High Power Audio System for Cars, Trucks & SUVs - Perfect for Upgrading Your Vehicle's Sound System

$274.99 $499.99 -45%

Delivery & Return:Free shipping on all orders over $50

Estimated Delivery:7-15 days international

People:21 people viewing this product right now!

Easy Returns:Enjoy hassle-free returns within 30 days!

Payment:Secure checkout

SKU:41459611

Guranteed safe checkout
amex
paypal
discover
mastercard
visa

Product Description

Engineered specifically for powersports applications, the 3-channel MX600/3 amplifier employs our high-speed NexD™ switching design to deliver plenty of clean power, without straining charging systems. Its tiny, cast aluminum housing is highly resistant to corrosion, with an IPX7 water-resistance rating, making it perfect for motorcycles, ATV’s or other utility vehicles.

Generating a potent 75W x 2 into 4 ohms, plus a solid 400 watts for a subwoofer system, the MX600/3 makes a great all-in-one solution for driving a complete audio system from a single, ultra-compact chassis.

Onboard filters include a 12 dB / octave high-pass crossover on the main channels and a dedicated 24 dB / octave low-pass crossover for the subwoofer channel. Other features include a bass boost EQ, variable infrasonic filter and subwoofer output polarity switch. A dual-range input section accepts a wide range of input voltage levels, from line-level all the way to high-power speaker level signals.

This amplifier features a rugged powder-coated finish, a gasketed cover for the controls and stainless steel hardware for durability.

NexD™ Switching Technology

NexD™ amplifier technologies produce exceptional audio quality, unsurpassed total efficiency and high power from very compact amplifier designs.


Differential-Balanced Inputs

JL Audio’s Differential-Balanced Inputs are engineered to combat induced cable noise, which is a common problem in car and marine audio installations. This technology allows for the use of conventional RCA cables, while delivering many of the benefits of a true balanced connection and accepting a wide range of input signal levels.

|



Weather ResistanceIPX7

Number of Channels

3

Class

D

Peak Power Rating (Watts)


RMS Power Rating (Watts x Channels) - 4 Ohms

75 x 4

250 x 1

RMS Power Rating (Watts x Channels) - 2 Ohms

100 x 2

RMS Power Rating - Bridged200 x 1
Minimum Impedance Unbridged (Ohms)

2

Minimum Impedance Bridged (Ohms)

4

THD at Rated RMS Power

1%

Bulit-in Crossover - Low Pass

Yes

Built-in Crossover - High Pass

Yes

High Pass Crossover Frequency (Hz)

40-400Hz

Low Pass Crossover Frequency (Hz)
35-300Hz
Signal-to-Noise Ratio


Bass Boost
No
Bass Remote Included

No

Fuse Rating50A
CEA-2006 CompliantYes
Maximum Power Wire Gauge Size4 Gauge
Warranty1 Year
