JL Audio M600/6 24V 6-Channel Marine Amplifier - 600W Class D Full Range Power for 24V Boat Audio Systems | Perfect for Marine Stereo Upgrades & Watercraft Sound Enhancement
JL Audio M600/6 24V 6-Channel Marine Amplifier - 600W Class D Full Range Power for 24V Boat Audio Systems | Perfect for Marine Stereo Upgrades & Watercraft Sound EnhancementJL Audio M600/6 24V 6-Channel Marine Amplifier - 600W Class D Full Range Power for 24V Boat Audio Systems | Perfect for Marine Stereo Upgrades & Watercraft Sound EnhancementJL Audio M600/6 24V 6-Channel Marine Amplifier - 600W Class D Full Range Power for 24V Boat Audio Systems | Perfect for Marine Stereo Upgrades & Watercraft Sound Enhancement

JL Audio M600/6 24V 6-Channel Marine Amplifier - 600W Class D Full Range Power for 24V Boat Audio Systems | Perfect for Marine Stereo Upgrades & Watercraft Sound Enhancement

$456.49 $829.99 -45%

Delivery & Return:Free shipping on all orders over $50

Estimated Delivery:7-15 days international

People:10 people viewing this product right now!

Easy Returns:Enjoy hassle-free returns within 30 days!

Payment:Secure checkout

SKU:69087319

Guranteed safe checkout
amex
paypal
discover
mastercard
visa

Product Description

This incredibly flexible amplifier packs a serious full-range punch, and delivers a staggering 100 watts to each of its six channels into 2 Ω (28.8V, 1% THD). The breakthrough that makes this much power possible in such a small chassis is our NexD™ ultra-high-speed switching design, which allows for full bandwidth Class D operation with extremely low distortion and outstanding efficiency.

With the M600/6-24V, you have lots of great options. Use it as a six-channel satellite amplifier with 75 W x 4 @ 4 Ω, or bridge four of its channels to create a staggered power four-channel amplifier with 200W x 2 @ 4 Ω to one pair of satellites and 75 W x 2 @ 4 Ω to a secondary pair of satellites. You can also drive two subwoofers with 200 W each, plus a pair of satellites with 75W x 2. The M600/6-24V includes a 12 dB / octave filter for each channel bank, which can be configured as a low-pass or high-pass filter and offers continuously variable cutoff frequency selection from 50-500 Hz. With the addition of an HD-RLC remote level control (sold separately), you have the ability to control the level of two, four or all six of the amplifier's channel levels from a remote location.

This marine amplifier features white and gray powder-coat finishes, a gasketed cover for the controls and stainless steel hardware for durability in the marine environment.

This amplifier is designed for operation in vessels with 24 volt, negative-ground electrical systems. Use of this product in vessels with positive ground and/or voltages other than 24 V may result in damage to the product and will void the warranty.

NexD™ Switching Technology

NexD™ amplifier technologies produce exceptional audio quality, unsurpassed total efficiency and high power from very compact amplifier designs.


Advanced Rollback Protection

JL Audio's exclusive Advanced Rollback Protection circuit monitors the amplifier's thermal condition and adjusts amplifier operation to eliminate annoying amplifier shut-down events.

|



Weather ResistanceYes

Number of Channels

6

Class

D

Peak Power Rating (Watts)


RMS Power Rating (Watts x Channels) - 4 Ohms

 75 x 6

RMS Power Rating (Watts x Channels) - 2 Ohms

100 x 6

RMS Power Rating - Bridged200 x 3
Minimum Impedance Unbridged (Ohms)

2

Minimum Impedance Bridged (Ohms)

4

THD at Rated RMS Power

1%

Bulit-in Crossover - Low Pass

Yes

Built-in Crossover - High Pass

Yes

High Pass Crossover Frequency (Hz)

50-500Hz

Low Pass Crossover Frequency (Hz)
50-500Hz
Signal-to-Noise Ratio

104dB

Bass Boost
No
Bass Remote Included

No

Fuse Rating30A
CEA-2006 CompliantYes
Maximum Power Wire Gauge Size4 Gauge
Warranty1 Year
